ISO SS Ozone Resistance Test For Rubber Environmental Test Chamber

Name: ISO SS Ozone Resistance Test For Rubber Environmental Test Chamber
Brand: Haida
Price: 1 USD

Quality ISO SS Ozone Resistance Test For Rubber Environmental Test Chamber wholesale

Brand Name : Haida

Model Number : HD-E801

Certification : ISO9001: 2008, CE, ...

Place of Origin : china

MOQ : 1 SET

Price : Negotiation

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, MoneyGram

Supply Ability : 300 sets per month

Delivery Time : 15 days after order confirmed

Packaging Details : Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.

Usage : Rubber Ozone aging test

Warranty year : 1 year

Interior Size (WxDxH) : 250x250x250mm

certificate : ISO,, CE etc

Accuracy : ± 1%

Temp. (optional) : Room temp.~200°C or 300°C

Motor : 1/4 HP

Electrothermal Tube : 3 KW

Weight : 250kg

Power : 1#, AC 220V/14.5A

Contact Now

ISO Ozone Resistance Test For Rubber Environmental Test Chamber

Introduce:

Aging chamber is widely used to control products quality in measuring quality control; Rubber & Plastics; automobile production; wire and cable; packing materials; instruments and meters; medical equipment; civilian nuclear energy; civil aviation; colleges and universities; research laboratories; inspection arbitration, and technical supervision departments and other rubber products.Rubber ozone aging Chamber is a major factor in rubber cracking although it is rare in the atmosphere, ozone aging tank simulates and enhance the condition of ozone in the atmosphere to study the effects of ozone on rubber, and then identify and evaluate the method to resist ozone and aging for rubber, adopt effective anti-aging measures to enhance the life of rubber products.

Main feature:

Equipment by the occurrence of silent and efficient ozone generator ozone gas, and a certain amount of air processed, the switch in the mixture into the chamber, the continuous line UV detector to detect the concentration of ozone, ozone generator control feedback to the systems to control system settings according to the occurrence of effective control of ozone to the ozone chamber to maintain the appropriate concentration of work by heating humidification systems to meet all the test conditions.

Main function:

Aging Chamber can be used to test rubber products with static tensile deformation, such as vulcanized rubber, thermoplastic rubber, cable insulating bush; expose the test specimens to the sealed air in the test chamber without light and with constant ozone concentration and constant temperature according to predetermined time, and then observe the cracks on test specimens’ surface and the degree of change of other properties to evaluate the rubber’s ozone aging resistance properties.

Technical parameter:

Model	HD-E801 ozone aging test chamber
Ozone concentration	5~200pphm (adjustable) 200~1000pphm(adjustable)
Relative humidity	No humidity, but can produce according to your requirement
Temperature	RT+10~+70°C
Ozone produced mode	Ozone generator or UV absorption method
Inside air velocity	over 2 feet/sec
Degree of ozone concentration fluctuation	10%
Inside size	500×500×600mm
air flow	A.0-6 cfm;B. 10-20 cfh
weight	250kg
power	1# ,AC220V,15A
accessories	tensile fixture 6 groups

Corresponding standard:

JIS K 6259 , ASTM1149 , ASTM1171, ISO1431, DIN53509 , GB/T13642, GB/T 7762-2003

GB 2951
